Axiom Memory Solutions

Axiom MPO Female to MPO Female Multimode OM4 50/125 Fiber Optic Cable - 5m

Axiom MPO Female to MPO Female Multimode OM4 50/125 Fiber Optic Cable - 5m

ETS4146060

$181.95 USD
$181.95 USD
Sale Sold out

26 in stock

  • Axiom MPO Cables are designed to be used in any high-density fiber optic environment, such as digital cross-connects, optical backplanes, parallel processing applications, and Fibre Channel storage facilities.
  • Features:
  • Flame-Retardant Jacket
  • Polished end-face quality to IEC 61300-3-35 standard
  • 12 fibers
  • Push on / Pull-off latching connector
  • Precision guide pin assures fiber alignment
  • Cable Specs:
  • 50/125 OM4 MMF cable
  • (2) MPO/MTP Female connectors at both ends
  • Fiber Count: 12
  • Jacket Type/Flame Rating: Riser (OFNR)
  • Jacket Color: Aqua
  • Termination Type/Polarity: Rolled - Key up / Key up Pin 1-12 style
  • Compliance: RoHS Compliant, TIA/EI942, ISO/IEC 24764, EN 50173-5
  • Insertion Loss, Typical: = 0.35dB
  • Return Loss, Maximum: = -20dB
  • Connector Order:
  • 1 - 12 2 - 11 3 - 10 4 - 9 5 - 8 6 - 7 7 - 6 8 - 5 9 - 4 10 - 3 11 - 2 12 - 1

    • Offers a reliable network connectivity
    • Features Fiber Optic cable type
    • Features Flame Retardant
    • 2 x MTP/MPO Female Network offers a secure and reliable connection with a compatible network device
